| Place of Origin: | China |
| Brand Name: | kingteli |
| Certification: | CQC,TUV |
| Model Number: | 501601 |
| High Light: | energy regulator,infinite switch,kingteli |
||
|---|---|---|---|
1,Switch Rating:
13.5A 230V AC MAX. RESISTIVE
TUNGSTEN HALOGEN(BALLAST LOAD)
SIGNAL CONTACTS:
S1-S2 0.1A 400V AC MAX. RESISTIVE
2,Temperature Rating:
T125C MAX. CONTINUOUS
3,Output Characteristics:
CONTINENTAL SCALE, OPERATING RANGE 52~308
3~9% AT 52
45~73% AT 258
100% AT 308 (INDEXED FULL POSN.)
4,INDEXING: OFF POSITION&FULL POSITION
5,MOUNTING:TWO-SCREW FIXING. 2*M4 SCREWS AT 28MM CENTRES-MAX SCREW INSERTION 5MM.
6,OFF POSITIONAL ACCURACY:3
7,TERMINATIONS: ALL 6.3MM TAB
8,APPROVALS: CE,TUV,CQC
